Non-contact process control using the pulse-echo method for monitoring the curing of fibre-reinforced plastic components

Grasse Zur Composite Testing develops together with DLR e.V. a non-contact process control using the pulse-echo method as part of a ZIM research project funded by BMWi. Due to the increasing networking of control and plant systems, real-time information on the curing process is of increasing interest in the processing of fibre-reinforced plastics.

The GZ US-Plus® non-contact process control system has been successfully represented on the market for about twenty years. Compared to competing methods such as di-electric analysis (DEA), it has the advantage of being able to measure without direct contact to the manufactured component. The ultrasonic-based system uses a piezo sensor to emit sound waves that are received by a second sensor. A computer calculates the curing process from the running time. This method of process control is particularly important for the aerospace industry, since no holes have to be drilled into the moulds and thus the elaborately machined surfaces of the closed moulds are not damaged.

The limitations of the previous reference technology become apparent in the case of rotor blades of wind turbines. These components are manufactured in open-mold construction and are nowadays up to 80 m long. Under the often harsh production conditions, it is not possible to measure the curing in transmission by means of two sensors (transmitter and receiver). Practical experience shows that only a permanently installed sensor system, which does not hinder but supports the workflows in production, can be implemented in production.

For this reason, the development of OPtimus® was initiated, in which the curing control is realised by means of a coupled transmitter-receiver unit using the pulse-echo method. This technology eliminates the need for a second sensor, which is why the sensor system can remain permanently integrated in the mold. This enables both an enormous increase in efficiency during curing and a guarantee of networking within the scope of QA. Flow front detection is also the current development status, which is expected to be ready for the market in 2022.

Contact

Grasse Zur Composite Testing GmbH, Dr. Fabian Grasse, fabian.grasse@grassezur.de, +49 30 7790791-50

DLR e.V., Hakan Ucan, hakan.ucan@dlr.de, +49 531 295-3709



Webinar “Test methods for determining the intralaminar shear properties of FRP”

In cooperation with Composites United the webinar “Test methods for determining the intralaminar shear properties of fibre-plastic composites” took place on 19 May 2020. Dr. Fabian Grasse went into detail about the characterisation of the shear properties of FRP.

Various test methods have been established for determining the intralaminar shear properties of FRP. These differ in the geometry of the test specimens and the type of load application, which means that different testing devices are used. This webinar will introduce the most widely used standards for the determination of shear characteristics (DIN EN ISO 14129, DIN EN ISO 20337, ASTM D5379 and ASTM D7078) and go into detail about the various advantages and disadvantages of the respective test methods.

Link to the webinar



Get in touch with us at Composites Europe 2019

This year, for the first time in seven years, we are not represented with our own stand at Composites Europe. Nevertheless, you have the opportunity to speak personally on site with the Grasse Zur Composite Testing team about material testing on fibre-reinforced plastics, testing services in our ISO 17025 accredited testing laboratory or reference test fixtures such as the picture frame. Simply select an appointment from the list. You will then receive a confirmation email.

We are looking forward to a personal conversation!



Werkstudent

Copyright Federal Institute for Materials Research and Testing (BAM) 2014

We are happy to carry out material tests on fibre-reinforced plastics for you in our ISO 17025 accredited test laboratory, even during the summer break. So you can go on holiday with peace of mind and the test results will be on your desk afterwards. Our experience shows that the number of incoming orders increases considerably after the summer holidays, which can lead to delays in order processing. Therefore we would like to give you some references in own thing:

  • The Grasse Zur team does not take company holidays and is always available for you during the summer.
  • Incoming orders are processed in the order in which they are received. For this reason, it is advantageous to place an testing order even if the material to be tested is not yet available. This allows us to better schedule the tests and procure the necessary aids in good time, such as ordering strain gauges.
  • We are always at your disposal for all questions concerning composite testing.

Contact us simply and without obligation, we will be happy to advise you!


Demo Image

Copyright Theo Reinhardt

The Grasse Zur Composite Testing team congratulates Theo Reinhardt and Roger Kluge on winning the 108th Berlin Six-Day Race. This victory would not have been possible without their FES track bike.

We are proud to test for the Institute for Research and Development of Sports Equipment (FES)!
